UL3G 55 Class 4K UHD Conference Room & Digital Signage IPS LED Display
Product Description
Advertise your business or conduct efficient meetings with the LG UL3G 55 Class 4K UHD Conference Room & Digital Signage IPS LED Display. It features native 4K UHD resolution for playback of compatible media in enhanced detail, and its maximum brightness level of 400 cd/m² and 1200:1 contrast ratio help improve visibility in high-brightness environments, such as a storefront window or a bright office setting.
The onboard webOS 4.1 operating system allows for smart functionality for an intuitive user experience. The UL3G is compatible with third-party control systems, such as Crestron Connected, as well as Cisco conferencing systems. A suite of LG SuperSign software helps you get the display running quickly and easily.
The onboard webOS 4.1 operating system allows for smart functionality for an intuitive user experience. The UL3G is compatible with third-party control systems, such as Crestron Connected, as well as Cisco conferencing systems. A suite of LG SuperSign software helps you get the display running quickly and easily.
| Display | |
| Screen Size (Diagonal) | 55" |
| Resolution | 3840 x 2160 |
| Supported Display Resolutions | |
| Panel Type | IPS-Type LCD |
| Bit Depth / Color Support | 8-Bit (16.7 Million Colors) |
| Color Gamut | 80% DCI-P3 |
| HDR Compatibility | |
| Brightness | 400 cd/m� (Typical) |
| Viewing Angle (H x V) | 178 x 178° |
| Screen Area | |
| Aspect Ratio | 16:9 |
| Contrast Ratio | 1200:1 |
| Dynamic Contrast Ratio | 1,000,000:1 |
| Response Time | 8 ms (GtG) |
| Refresh Rate | 60 Hz |
| Horizontal Frequency | |
| Vertical Frequency | |
| Dot Pitch | |
| Pixels Per Inch (ppi) | |
| Backlighting Technology | Direct LED |
| Pixel Clock Frequency | |
| Connectivity | |
| Primary Connectivity Location | Display |
| Input Ports | 2 x HDMI (Side) 1 x HDMI (Rear) |
| Output Ports | 1 x 1/8" / 3.5 mm – Audio (Rear) |
| USB Ports | 2 x USB 2.0 Type-A (Side) |
| Ethernet Ports | 1 (Rear) |
| Control | RS-232C via RJ11 In RS-232C via RJ11 Out |
| Wi-Fi | Built-in |
| Bluetooth | Yes |
| General | |
| TV Tuner | No |
| Display Orientation | Landscape, Portrait |
| Maximum Multiple Display Configuration | |
| 3D | |
| Ambient Light Sensor | Yes |
| Lighting Lifespan | |
| Surface | |
| Haze Level | 1% |
| Audio | |
| Built-In Speakers | Yes |
| Processing | |
| Hardware | |
| Operating System | webOS 4.1 |
| Processor | |
| Storage | |
| RAM | 8 GB |
| Supported File Systems | |
| GPU | |
| Chipset | |
| Slot | |
| Operating System Support | |
| Convenience | |
| Built-In Mic | |
| NFC | |
| Supported Video File Types | H.265/HEVC |
| Supported Audio File Types | |
| Supported Photo File Types | |
| Supported Document File Types | |
| Picture in Picture (PIP) | |
| Supported Languages | |
| Swivel Adjustment | |
| Tilt Adjustment | |
| Electrical | |
| Power Consumption | Typical: 105.0 W Maximum: 155.0 W Economy Mode: 73.5 W Standby: 0.5 W |
| AC Input Power | 100 to 240 VAC, 50 / 60 Hz |
| AC Input Power | |
| DC Input Power | |
| Power Adapter Type | Internal |
| Apparent Power | |
| Environmental | |
| Operating Temperature | 32 to 104°F / 0 to 40°C |
| Storage Temperature | |
| Operating Humidity | 10 to 80% |
| Storage Humidity | |
| Operating Altitude | |
| Storage Altitude | |
| Operating Shock | |
| Operating Vibration | |
| Certifications | |
| Physical | |
| Wall Mounting | 300 x 300 mm |
| Material of Construction | |
| Audible Noise | |
| IP Rating | |
| IK Rating | |
| IR Sensor | |
| Glass Thickness | |
| Bezel Thickness | 15.5 mm (Right/Top/Left) 22.3 mm (Bottom) |
| Duty Cycle | 16 Hours / 7 Days |
| Dimensions | 49.0 x 28.6 x 3.4" / 1244.0 x 726.0 x 87.1 mm (without Stand) 49.0 x 30.9 x 9.1" / 1244.0 x 786.0 x 231.0 mm (with Stand) |
| Weight | 31.5 lb / 14.3 kg (without Stand) 32 lb / 14.5 kg (with Stand) |
| Warranty Length | Limited 3-Year Warranty |
